GT35L28 heavy duty linear actuator is a high-performance 24V electric actuator designed for heavy-duty applications. Water resistant linear actuator is very suitable for use in environments where moisture is a concern due to its waterproof function.. This 300mm linear actuator provides precise, reliable linear motion for a wide range of medical and therapeutic devices. Its high force output ensures smooth, controlled movement, making it perfect for use in hospital beds, patient lifts, and massage tables.
Equipped with a powerful electric motor, the GT35L28 actuator 24v is a high force electric linear actuator capable of handling demanding applications that require robust and consistent performance. It is commonly used in medical equipment such as hospital beds and treatment chairs, where precise adjustments are necessary for patient comfort. This hospital bed linear actuator ensures smooth, quiet, and stable movement, making it an essential component in healthcare and therapy equipment that demands high reliability.
Voltage : 24 VDC
Stroke length:
Standard version
1,500 N: 50 – 405 mm (in steps of 5 mm)
4,000 N: 50 – 300 mm (in steps of 5 mm)
6,000 N: 50 – 200 mm (in steps of 5 mm)
8,000 N: 50 – 250 mm (in steps of 5 mm)
Patient lift version
8000 N: 50 – 300 mm (in steps of 5 mm)
6000 N: 50 – 400 mm (in steps of 5 mm)
Load in push: 1500,4000,6000,8000
Color: gray
IP grade: Max. IPX6
Installation dimensions:
Standard version:
L=S+185（50≤S≤250，standard）
Patient lift version：
L=S+260（50≤S≤300，with manual）
L=S+290（300<S≤400，with manual）
Noise level: ≤48dB, ( environmental noise≤40dB)
Usage temperature: +5 °C to +40 °C
Safety nut: standard
Hall sensor : optional
Only push no pull : optional
manual operation:optional
Built-in electrical limit switch.
Weight: About 3kg (different stroke length and installation dimensions with different weight )
Static bending moment: lateral load are not allowed.
Height above sea level Max： 3,000 meters
GT35L28 linear actuator motor versatility allows it to be applied in various settings, such as massage tables, image equipment, and patient lifts. Its durability and water-resistant features make it suitable for environments where cleanliness and patient safety are top priorities. Whether adjusting the height of a massage table or repositioning a patient in a lift, the GT35L28 provides the precision and strength needed for optimal performance. Its heavy-duty design ensures long-lasting, reliable service across multiple applications in healthcare and treatment environments.
